TIG ACDC welder / GTAW welder / GTAW welding machine / ACDC TIG welder / Aluminum TIG welder

TIG

TIG welder,GTAW welding machine

TIG (AC/DC PULSE)

TIG ACDC welder / GTAW welder / GTAW welding machine / ACDC TIG welder / Aluminum TIG welder

● Description

Inverter IGBT.
HF stabilizing technology.
Multiple-AC waveforms.
Water cooled option available.
Full-featured pulse TIG parameters.
Overcurrent and overheat protection.
Key power electronic component protection.
Stable ARC with less spatter and good shaping.
Digital control technology enhances performance.
Mixed waveform, mixed waveform frequency, mixed wave duty cycle.
Excellent performance with Pulse TIG, especially for thin material welding.
    Request A Quick Quote
    product details

    ● Product Parameters

    2T/4T/Special 4T/SPOT;

    AC TIG / DC TIG / AC MMA / DC MMA;

    Sine wave/triangle wave/square wave;

    Real Initial current : 10A;

    DC pulse frequency adjustable range: 0.2-500Hz;

    AC pulse frequency: 0.2-200HZ;

    AC frequency: 20-250HZ;

    Programme saving;

    TIG torch can control output amper up/down;

    Option:

    3KHZ DC pulse frequency;

    16 waves.

    ● Product Parameters

    Model TIG-225P  ACDC TIG-255P  ACDC TIG-300P  ACDC TIG-315P  ACDC TIG-350P  ACDC TIG-400P  ACDC TIG-500P  ACDC TIG-630P  ACDC
    Rated Input Voltage(VAC) 1P 220 3P 380
    Rated Input  Power(KVA) 6.2 11.2 8.2 11.2 15.8 17 25 28.3
    No-Load Voltage(V) 67 67 74 69 69 81 78V 82V
    Max Rated Output(A/V) 200/18 250/20 280/21 .2 315/22 .6 350/24 400/26 500/30 630/34
    Adjustable Current Range(A)(TIG) 10-200 10-250 10-280 10-315 10-350 10-400 10-500 10-630
    Real Output Current(A)(TIG/MMA) 200/19 0 250/24 0 280/26 0 315/30 0 350/33 0 400/40 0 500/50 0 630/63 0
    Arc Start Mode HF, untouch
    Output Characteristics Constant-current characteristic
    Enclosure Protection Class IP21S
    Duty Cycle(%) 40 40 50 50 50 100 100 100
    Efficiency(%) 80
    Insulation Class(%) F
    Gas Regulation Pre-Gas(S) 0.1-10
    Post-Gas(S) 0-10
    Current Start(A) DC:5-400/AC:20-400
    Stop(A) DC:5-400/AC:20-400
    Slope Up(S) 0.1-10
    Slope Down(S) 0-10
    Pulse Frequency(Hz) 500
    Balance (%) 20-70
    AC Frequency(Hz) 200
    Power Factor 0.8 0.8 0.9 0.9 0.9 0.9 0.9 0.9
    Weight(KG) 13.75 18.3 19.9 29 34.6 46.5 72 78
    Machine Dimension(MM) 375*425*225 475*235*410 475*235*410 510*265*470 585*295*530 645*330*615 630*355*865 630*355*865
