| Position |
Code |
Ref. |
Description |
| 1 |
KSM0069 |
W0300177 |
Four pointed spacer/LT101-141 |
| 2 |
KSM0067 |
1408/W0300131 |
Double pointed spacer/LT101-1501 |
| 3 |
KSM0066 |
W0300130 |
Spacer spring LT100-151 |
| 4 |
KVS0082-05 |
W0300129 |
Outside nozzle LT100/grey |
| 5.1 |
KVU0071-11 |
1371/W0300125 |
Tip Φ 1.1mm LT100-150 |
| 5.2 |
KVU0071-13 |
1372/W0300174 |
Tip Φ 1.3mm LT100-150 |
| 5.3 |
KVU0071-16 |
1373/W0300175 |
Tip Φ 1.6mm LT100-150 |
| 6 |
KSM0099 |
W0300184 |
Locking nut |
| 7 |
KSM0083 |
W0300180 |
Spacer for contact cutting/LT100-150 |
| 8 |
KVS0083-05 |
W0300138 |
Contact nozzle retaining cap/LT100/grey |
| 9.1 |
KVU0073-13 |
W0300135 |
Flat tip Φ 1.35mm/LT100-150 |
| 9.2 |
KVU0073-16 |
W0300137 |
Flat tip Φ 1.6mm/LT100-150 |
| 10 |
KVF0004 |
1377/W0300124 |
Diffuser LT100/150 |
| 11 |
KVB0089 |
1376/W0300123 |
Electrode HF LT100/150 |
| 12 |
KZN0769 |
W0300122 |
Air tube/CB100 |
| 13 |
KSM0003 |
W0300182 |
Shield cap hand tip (Max 50A)/LT100-151 |
| 14 |
KSM0004 |
W0300183 |
Spacer for contact cutting hand tip /LT100-151 |
| 15 |
|
|
Tip |
| 15.1 |
KVU0075-13 |
W0300178 |
Extended tip Φ 1.3mm/LT100-150 |
| 15.2 |
KVU0075-16 |
W0300179 |
Extended tip Φ 1.6mm/LT100-150 |
| 15.3 |
KVU0075-18 |
|
Extended tip Φ 1.8mm/LT100-150 |
| 15.4 |
KVU0080-11 |
1369/W0300134 |
Contact extended tip /LT100-150 |
| 16 |
KVB0095 |
1517/W0300133 |
Extended electrode HF Plasma LT100-150 |
| 17 |
KZN0762 |
|
Extended air tube/LT100 |
| 18 |
KVF9006 |
|
Front insulator/LT100-101 |
| 19 |
KVZ0025 |
|
Plasma torch head LT100 |
| 19a |
KFT0689 |
1398/W0300121 |
"O"ring Φ18*Φ.21.6MM*1.8/LT150/RED SILICONE |
| 20 |
KGV0035 |
|
Plasma handle manual/A Series/Red |
| 21 |
KHJ0722 |
|
Protection part/Plasma/Yellow |
| 22 |
KHQ0070 |
185.0031 |
Trigger Red |
| 23 |
KHJ0894 |
|
tig Joint/big/new type |
| 24.1 |
KVN00210066-00 |
|
Cable assembly/LT100-101/10MMQ/6M ATT.1/8G |
| 24.2 |
KVN00210060-00 |
|
Cable assembly/LT100-101/10MMQ/6M central adaptor |
| 24.3 |
KVN10210066-00 |
|
Cable assembly/LTM100-101/10MMQ/6M ATT.1/8G |
| 24.4 |
KVN10210060-00 |
|
Cable assembly/LTM100-101/10MMQ/6M central adaptor |
| 25 |
KCG6006 |
|
Spanner for Plasma |
| 26 |
KVZ0082 |
W0300143 |
Plasma torch head LTM100 |
| 26a |
KGV0013 |
W0300144 |
PLASMA HANDlE KIT/LTM |
| 27.1 |
KZT5687 |
|
Connecting adaptor 1/8G-1/4G |
| 27.2 |
KZT5688 |
|
Connecting adaptor 1/8G-M14×1 |
| 27.3 |
KZT5689 |
|
Connecting adaptor 1/8G-M16×1.5 |
| 27.4 |
KZX0078 |
|
Central adaptor torch side Plasma 5 pins |
| 28 |
KSM0077 |
169 |
Circle cutting attachment/LT101-151 |
| 28.1 |
ISM0076 |
|
Wheel spacer with spanner LT100-101 |
